RD 12/RD 12A Schematics
wc_tx001073gb.fm 127
10.9 Electrical Schematic Components—RD 12
Ref. Description Ref. Description
1 Work light switch 17 Left head light (optional)
2 Throttle switch 18 Right head light (optional)
3 Pump switch 19 To magneto kill
4 Key switch 20 Crank relay
5 Vibration indicator light (green) 21 Neutral relay
6 Low fuel indicator light (amber) 22 Spray bar pump
7 Alternator (30A) 23 Fuel cutoff solenoid
8 Starter solenoid 24 Reverse switch
9 Starter motor 25 Vibration switch
10 Battery 26 Neutral switch
11 Fuel level sensor 27 Seat switch
12 Vibration solenoid (front) 28 Strobe light (optional)
13 Throttle solenoid 29 Backup alarm (optional)
14 Pump timer module 30 Throttle relay
15 Hourmeter 31 Quick shut-off relay
16 Rear light (optional)
Wire Colors
B Black R Red Y Yellow Or Orange
G Green T Tan Br Brown Pr Purple
L Blue V Violet Cl Clear Sh Shield
P Pink W White Gr Gray LL Light blue
