TESTING YOUR PEN
If the pen does not work as you expect, it is a good idea to first check the assigned functions or reset the
pen to its default conditions. A quick way to reset a pen to its default settings is to remove it from the T
OOL
list by clicking on the list’s [ – ] button. After the pen has been removed, place it back onto the display
screen surface and the pen will be re-added to the T
OOL list with its default settings.
Open the Wacom Control Panel and click on the A
BOUT button. In the dialog box that appears, click on the
D
IAGNOSE... button to open the DIAGNOSTICS dialog box. The DIAGNOSTICS dialog box displays dynamic
information about the interactive pen display and pen. This information is used when testing the pen
display and your pen.
If more than one pen display unit is connected to your system, be sure to select the unit for which you are
testing in the T
ABLET INFO column.
Note: If the pen switch is set to R
ADIAL MENU or OPEN/RUN..., that function will occur when the switch is
pressed. In this case you may want to change the switch’s function before testing.
1. While observing the P
OINTING DEVICE INFO column, bring your pen within 5 mm (0.2 inch) of the display
screen. A value for P
ROXIMITY, the DEVICE NAME, and DEVICE TYPE should be displayed.
2. Move your tool along the pen display screen surface. The X and Y Data values should change to reflect
the tool position.
3. Test your pen switch. The pen display status LED should light blue each time you click with the pen tip
or press the switch.
• Press on the display screen surface with the pen tip. The S
WITCHES state and PRESSURE value
should change. (P
RESSURE should change from approximately 0% with no pressure applied to
approximately 100% when full pressure is applied.)
• Next, press the switch without pressing the tip to the display screen surface and the S
WITCHES state
should change.
4. When you are done, click on the C
LOSE button to exit the dialog box.
