WAGNER CONTROL 150 M User Manual

26
Control 150 M
GB
Make pump ready for operation
1) Make sure the inlet lter is in
place inside the hopper. If it
is not, snap in place as shown.
2) Press down the button on the
lter once. This will ensure
proper operation of the inlet
valve.
Button
We recommend performing the following steps with
water rst of all, in order to check that the system and all
connections are watertight.
3) Fill your hopper with the
material you plan to spray.
Do not exceed the ll line as
shown.
Fill line
4) Turn the PRIME/SPRAY knob
to PRIME.
5) Plug in the sprayer, and
move the ON/OFF switch to
the ON position.
6) Check that the material is
owing through the return
tube.
7) Switch the pump to OFF.
l
i
Mount the cover during operation. The cover
does not close airtight. Therefore, do not tilt
the device when lled.
Suck in material
Perform the following steps, without the spray tip
mounted to the gun.
1)
Unlock the spray gun and
turn the PRIME/SPRAY knob
to PRIME.
2) Trigger and HOLD the spray
gun into a waste container.
3) Switch the pump on.
WARNING
Keep hands clear from uid
stream.
4)
While holding the trigger,
turn the PRIME/SPRAY knob
to SPRAY. Hold the trigger
until all air, water, or solvent
is purged from the spray hose
and paint is owing freely.
l
5) Release trigger, turn the
PRIME/SPRAY knob to
PRIME and turn pump OFF .
O
6) Trigger the gun into the waste container once more to
be sure that no pressure is left in the hose.
7) Lock the spray gun o.
8) Thread the spray tip assembly onto the gun. Tighten by
hand.
9) Insert spray tip (tip pointing in the spray direction).
Your device is now ready for operation.
Preparation
