EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
5.2 TECHNICAL DATA
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) 85 VAC-250 VAC
Frequency 47 Hz-440 Hz
Input power maximum 40 W
Output voltage maximum 22 Vpp
Output current Max. 0.9A
High voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 μA-120 μA (adjustable in 1 μA steps)
Tribo current measuring range 0 μA-15 μA
Tribo current limitation 0 μA-5 μA (adjustable in 0.1 μA steps)
Tribo current cut o greater than 12 μA
(ATEX: switching o of the unit)
Protection class IP 64
Ex zone II 3(2)D 80 °C; 176 °F (Zone 22)
Pneumatic:
Input air pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air ow maximum 15 m³/h
Sum of dosing and feed air 1-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per ISO8573.1 6.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-45 °C; 41-113 °F
5.2.1 EPGSPRINT
