EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) input terminal 90 VAC-250 VAC
Frequency 47 Hz-63 Hz
Input power maximum 110 W
Mains (AC) output terminal Vibrator motor maximum 70 W
Output voltage spray gun maximum 22 Vpp
Output current spray gun Max. 0.9A
High voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 μA-120 μA (adjustable in 1 μA steps)
Tribo current measuring range 0 μA-15 μA
Tribo current limitation 0 μA-5 μA (adjustable in 0.1 μA steps)
Tribo current cut o greater than 12 μA
(ATEX: switching o of the unit)
Ex identi cation:
according to EN (ATEX, EN) II 3(2)D
according to Class & Division (North America) Class II, Division 2, Group E, F and G
Pneumatic:
Input air pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air  ow maximum 15 m³/h
Sum of dosing and feed air 1-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per
ISO8573.1, 2010
6.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-40 °C; 41-104 °F
5.2.3 EPGSPRINT XE
