WAGNER EPG-SPRINT Original Service Manual

88
EPG-SPRINT / EPG-SPRINT X
L N
JF3
+24VDC
GND
1 2 3 4 5 6 7 8
JD1
Spraygun plug
Fuse 2 1.6AT
PR
P
rot/red
blau/blue
1 2 3 4 5 6
JD2
#2304460
Pistolenstecker
P
24V+
#2304460 #2304460
GND
+24VDC
L N
PE
1 2
L N
PE
1 2
Main Switch 9953536
Change from outside 2x Fuse FST 5x20
1A slow blow 9951117
2x Fuse holder FPG1
2348276
Power IN plug STASEI200 9952587
Earth / Ground
Power OUT plug STAKEI200
Earth connector to lid Erdverbindung zum Deckel
Air distribution and regulation Luftverteilung und Einstellung
Atomizing air/Zerstäuberluft Dosage air/Dosierluft Feed air/Förderluft Drucklufteingang 6.5-8bar
94-116psi
Air mains supply 6.5-8bar
Pressure regulator 6bar Druckregler 6bar
Interlock/Remote to CCM-Prima
Fault Out Fault Reset Start/Stop +24VDC GND Recipe select Grounmonitor Gun trigger+ not used Coil+ Coil- GND/EARTH Gun trigger- Tribo current
PCB EPG-Sprint X Back Schematic SCH-3214D
GND
Mains power supply EPS-45-24 9953536 Input: 90-264VAC/47-63Hz Output: 24VDC 1.9A
JF4
GND
JF10
JF9
Relais
GNDGND
Fuse FS1 T2.5A soldered on PCB
Phase: braun/brown Neutral: blau/blue
P_03257
PCB EPG-Sprint X Display Schematic SCH-3215C
10 pol
Valve1
24V+
Valve2
24V+
Valve3
P
JF4
JF3
JF2
JF1
JF5
JF6
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
13 BLOCK DIAGRAMS
EPG-SPRINT X
