EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
8.1 TEST PARAMETERS
The test parameters can be found at the service level C31-C34 (see Chapter 9.1).
Parameter Display Description
C31 "AFC" Check air outlets: Indication of o set values / correction factors, check air
controllers individually
C32 --- Not assigned; this is indicated by "---"
C33 "LEd" Display and operating elements test
C34 "lot" Input and output test
C35 - C40 "---" Not assigned; this is indicated by "---"
8.2 CALIBRATION PARAMETERS
The calibration parameters can be found at the plant level C41-C44 (see Chapter 10.1).
Parameter Display Description
C41 "PrE" Pressure = operating pressure measured inside the equipment
(readjust pressure regulator)
C42 "AFA" Calibrate air outlets: Indication of o set values, calibrate and manually
adjust the correction factors, check air controllers individually
C43 "rES" Master reset: Reset entire EEPROM to WAGNER's default setting
C44 "HVA" High-voltage calibration
C45 "AFo" Default setting of o set for air channels
This is a default setting that must be performed in case of a sensor or PCB
replacement.
The menu is also used for controlling the setting.
C46 - C50 "---" Not assigned; this is indicated by "---"
