61
EPG-SPRINT / EPG-SPRINT X
P_01272
P_01273
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
9.1 PARAMETER C31, CHECKING AIR OUTLETS
9 SERVICE LEVEL
Purpose:
– To check AFC channels with an air ow measuring device
– To display calibration values and check the air volume controller
Note:
This function can only be undertaken with an appropriate air flow measuring device
(see Chapter 11, Measuring Equipment).
No values are changed for parameter C31.
The input pressure must remain at least 0.65 MPa; 6.5 bar; 94.27 psi during the test.
We would recommend using only high-quality ow measuring equipment. Simple measuring
equipment, be it electronic or based on the oat principle, is too imprecise over the entire
range and will provide poor absolute values.
Measuring equipment Measurement structure
