EPG-SPRINT / EPG-SPRINT X
SERVICE MANUAL
VERSION 09/2017 ORDER NUMBER DOC2309350
Error code E15
No signal from the PIC processor could be
received for 4 seconds.
Fault recti cation: Replace the rear panel circuit board.
Error code E16
Operating voltage monitoring output stage
determines an operating voltage outside of the
foreseen limits.
Fault recti cation: Replace the rear panel circuit board.
The device is switched o .
Error code E17
Too low of an operating voltage value during
coating
Fault recti cation: Replace the rear panel circuit board.
Error code E18
This error is shown due to an internal calculation and
plausibility check of high-voltage setting <60kV, coil
current >1.5V and spray current <5μA.
Troubleshooting:
1. Gun connector and bushing on control unit
(bent and soiled contacts)
2. Gun cable (broken strands or shield)
These parameters may never be reached together,
if all parameters and external in uences are correct.
3. Cable connection part on the gun
(correct and permanent connection)
4. Cascade plug
(bent and misshaped contacts)
5. High-voltage test
(Continuity test according to service manual)
6. Nozzle area
(Check for clean contacts and electrode tip,
functioning spring contact and contact ring, bent or
broken electrode tip)
7. Workpiece and control unit earthed correctly as speci ed
8. Only a WAGNER gun is approved
9. If all points have been checked, the whole gun can be
replaced as a quick test.
Error code E20
The password was not set at the factory or has
been lost
Fault recti cation: Replace the rear panel circuit board
Error code E21
Rear panel or circuit board display or
connection cable defective
Fault recti cation:
Check 10-pin connection cable and plug
Replace rear panel or circuit board display
Error code E22
Write or read error from internal EEPROM Fault recti cation: Replace the rear panel circuit board
