WANHAO I3 Plus - Control Panel Menu Map

Installation
Position:
• Home All: Returns Extruder and bed to home position using stop switches
• Home X / Y / Z: Returns specic axis to home position using stop switches
• X / Y / Z Pos. Fast: Quickly adjust the location of a specic axis
• X / Y / Z Position: Precisely adjust the location of a specic axis
• Extr. Position: Adjust the Extruder driving motor to feed, insert or remove lament
Extruder:
• Bed Temp: Manually set the bed temperature 30°C and 70°C
• Temp. 1: Manually set the Extruder temperature between 170°C and 240°C
• Extruder 1 Off: Quickly return the Extruder temperature to 0°C
• Extr. Position: Adjust the Extruder driving motor to feed, insert or remove lament
• Set Origin: Returns Extruder position value to 0mm
Fan Speed: Adjust the Extruder cooling fan to your desired percentage
SD Card:
• Print File: Select a le to be printed from the MicroSD Card
• Mount Card: If inserting the MicroSD Card after the 3D printer has initiated, card can be
mounted using this setting
• Unmount Card: Safely unmount the MicroSD Card
• Delete File: Select a le to be deleted from the MicroSD Card
Debugging:
• Echo: Off. Echo GCODE steps to conrm what has been received
• Info: On. Show printing information on the main display
• Errors: On. Show errors on the main display
• Dry Run: Off. Perform the GCODE steps without extruding any lament
AFTER SALES SUPPORT
86-571-23290996
support@wanhao3dprinter.com
Model : Duplicator I3 Plus
24
• Home All: Returns Extruder and bed to home position using stop switches
• Speed Mul.: Default 100%. Motor speed multiplier. Speed of the motor is
multiplied by this rate
• Flow Mul.: Default 100%. Printer ow multiplier. Amount of lament extruded is
multiplied by this rate
• Preheat PLA: Sets Extruder to 215°C and Heated Print Bed to 60°C
• Preheat ABS: Sets Extruder to 245°C and Heated Print Bed to 90°C
• Cooldown: Sets Extruder and Heated Print Bed to 0°C
• Disable Stepper: Disables all motors so they are free to be moved by hand
•
Print File: If an SD Card is mounted, les can be quickly accessed here.
1.5.2 Menu Map
Quick Settings:
