2004919_i•en•2017-09-01 We reserve the right to make technical changes
39
12 Technical data
WMS WebControl Min. Typ. Max. Unit
Supply
Operating voltage 5.0 V DC
Current 300 mA
RF transceiver
Transmission frequency 2.40 2.48 GHz
Transmission power 10 dBm
Reception sensitivity -101 dBm
WMS range ↵(environment without
interference)
30 m
Housing
WMS WebControl
(L×W×H in mm)
100.7 × 73.6 × 26.5
Degree of protection IP20
Safety class III
Connection
Supply voltage MicroUSB
Ethernet RJ45 plug-in connector
Miscellaneous
Automatic operation Type 1
Software class A
Location of use Clean ambient conditions, dry rooms (e.g.
living areas, offices)
Conformity
available at www.warema.de
Ambient conditions
Operating temperature 0 20 50 °C
Storage temperature 0 20 50 °C
Rel. humidity
(non-condensing)
10 40 85 %RH
Article numbers
WMS WebControl black 2003 877
WAREMA Renkhoff SE
Hans-Wilhelm-Renkhoff Strasse 2
97828 Marktheidenfeld
Germany
