Wartsila 46DF - Turbocharger Cleaning System

12.1 Turbocharger cleaning system
Fig 12-1 Turbocharger cleaning system (DAAF363744)
System components:
W46DF01
W46DF02
TC cleaning device5Z03
Air filter03
TC wash unit control04
Male stud GR18LR7105
Flow meter / control (10-105 l/min)06
Constant flow valve07
Flow meterAirWaterEngine
(0-80 l/min)System air for
scavening at low
load (l/min)
Water consump-
tion/wash (l)
Water inlet flow
rate (l/min)
Nom water inlet
press after press
contr. valve
Water inlet press
before contr.
valve (bar)
TurbochargerEngine
KK4DA-X-24024(4.0)5.0 - 8.0TPL71-C6L46DF
KK4DA-X-37037(4.0)5.0 - 8.0TPL76-C7L46DF
KK4DA-X-37037(4.0)5.0 - 8.0TPL76-C8L46DF
KK4DA-X-37037(4.0)5.0 - 8.0TPL76-C9L46DF
12-2 DBAD209883
Wärtsilä 46DF Product Guide12. Turbocharger Cleaning
