Fig 18-4 Main engine arrangement, 4 x V46DF (DAAR038996)
ATurbochar-
ger
Engine type
5900ABB-A17012V46DF
5900ABB-A17014V46DF
6200ABB-A17516V46DF
C [mm]B [mm]
2)
A [mm]
1)
Engine type
min. 19003200590012V46DF
min. 19003200590014V46DF
min. 19003200620016V46DF
1)
Minimum distance between engines.
2)
Depending on the type of gearbox.
Intermediate shaft diameter to be determined case by case.
18.2 Space requirements for maintenance
18.2.1 Working space around the engine
The required working space around the engine is mainly determined by the dismounting
dimensions of engine components, and space requirement of some special tools. It is especially
