19. Transpor t Dimensions and Weights
19.1 Lifting of engines
Fig 19-1 Lifting of rigidly mounted in-line engines (4V83D0212c)
Weights without flywheel [ton]H
[mm]
Y
[mm]
X
[mm]
Engine type
Total
weight
Transport
cradle
Lifting
device
Engine
1066.53.596551016008115W 6L46DF
1386.53.5128551018609950W 8L46DF
1619.53.51485675186010800W 9L46DF
DBAD209883 19-1
