Wartsila 46DF User Manual

3. Technical Data
3.1 Introduction
This chapter contains technical data of the engine (heat balance, flows, pressures etc.) for
design of ancillary systems. Further design criteria for external equipment and system layouts
are presented in the respective chapter.
Separate data is given for engines driving propellers “ME” and engines driving generators
“DE”.
3.2 Wärtsilä 6L46DF
DE
DE Constant
Speed
ME
CPP Constant
Speed
ME
CPP Variable
Speed
Wärtsilä 6L46DF
Diesel
mode
Gas
mode
Diesel
mode
Gas
mode
Diesel
mode
Gas
mode
114511451145kWCylinder output
600600600rpmEngine speed
687068706870kWEngine output
2.382.382.38MPaMean effective pressure
Combustion air system (Note 1)
12.311.112.311.112.311.1kg/sFlow at 100% load
454545°CTemperature at turbocharger intake, max.
504550455045°CTemperature after air cooler, nom. (TE 601)
Exhaust gas system (Note 2)
13.411.013.711.013.711.0kg/sFlow at 100% load
11.58.411.68.410.78.5kg/sFlow at 75% load
314365301367301367°CTemperature after turbocharger at 100% load
(TE 517)
305390292392294364°CTemperature after turbocharger at 85% load
(TE 517)
304407292409304346°CTemperature after turbocharger at 75% load
(TE 517)
306449
-
297450
-
298336
-
°CTemperature after turbocharger at 50% load
(TE 517)
444kPaBackpressure, max.
899847897849897849mmCalculated exhaust diameter for 35 m/s
Heat balance at 100% load (Note 3)
106884010808401080840kWJacket water, HT-circuit
187813862016138620161386kWCharge air, HT-circuit
858636882636882636kWCharge air, LT-circuit
762408768408768408kWLubricating oil, LT-circuit
204192204192204192kWRadiation
Fuel consumption (Note 4)
-7390-7410-7410kJ/kWhBSEC total at 100% load
-7530-7540-7420kJ/kWhBSEC total at at 85% load
DBAD209883 3-1
3. Technical DataWärtsilä 46DF Product Guide
