Fig 19-3 Major spare parts (DAAR039305)
Weight [kg]DescriptionItemWeight [kg]DescriptionItem
4.2Starting valve9615Connecting rod1
12Main bearing shell10211Piston2
-Split gear wheel11935.5Cylinder liner3
111Smaller intermediate gear121170Cylinder head4
214Bigger intermediate gear1310Inlet valve5
252Gear wheel to camshaft1410.6Exhaust valve6
2.5Piston ring set15142Injection pump7
0.5Piston ring25Injection valve8
DBAD209883 19-3
19. Transport Dimensions and WeightsWärtsilä 46DF Product Guide
