Wascomat TD67 - Technical Data; Drawing

Technicaldata
15
2Technicaldata
2.1Drawing
A
B(a)
E
C
B(b)
D
G
H
J
I
F
K
M
N
L
1
2
7
6
5
6
3
7
3
4
5
1
Operatingpanel
2
Dooropening,⌀810mm/⌀317/8inch
3Electricalconnection
4
Gasconnection
5
Exhaustconnection
6
Steam:in
7
Steam:out
A
B(a)B(b)C
DEF
G
mm
inch
960
3713/16
1315
513/4
1445
567/8
1855
737/16
660
26
720
283/8
170
611/16
1490
5811/16
HIJK
L
MN
mm
inch
200
77/8
180
71/16
1560
617/16
50
115/16
480
187/8
580
2213/16
805
3111/16
