Programunit
91
12.2Connections
Theprogramunitboardhasthefollowingconnections:
BoardconnectorFunction
J1
M-COM=Communication,motorcontrol
J2
D-BUS=Databus
J3
D-BUS=Databus
J4Tacho
J5
COIN=Input,coinmeter
J6
EMERG=Input,emergencystop
J7
FREE=Freeprogram(keyswitch)
J8
RS232=Serialcommunication
J9
Controlknob,pulses
J10
USBTYPEA=Connectionforsoftware/servicedownload
J12Display
J13Membranswitches
g.W00266
