I/Omodules
13.2ReplacementofI/Omodule
I/Omoduletype8andI/Omoduletype2areinstalledinthesameway.Ifthemachinehas
I/Omoduletype2,itislocatedonI/Omoduletype8.TheillustrationshowsreplacementofI/O
moduletype8.
Disconnectthepowertothemachine.
Demounttheupperrearpanel.
g.7442
128
Removetheelectricalconnectionsonthemodule.(Notethepositionoftheconnections).
Removethemodulebyliftingittowardsyouandupabitandthenpushingittotheleft.
