Wascomat TD67 - Replacement of Belt; Replacement of the Belt Around the Drum

74
Drum
11.3Replacementofbelt
11.3.1Replacementofthebeltaroundthedrum
Disconnectthepowertothemachine.
Demountthetworearpanels.
g.7215E
92
Demountthecoverplatetothebelttensioner.
OnmachineswithRMC;demounttheRMC(A).
A
g.7219B
93
Loosenthebelttensionerwithatorquewrenchbypullingthetensionplatecounterclockwiseto
thebottom.
g.7218
94
