Wascomat TD67 - Drum; Replacement of Drum

Drum
63
11Drum
11.1Replacementofdrum
Disconnectthepowertothemachine.
Demountthetworearpanels.
g.7215E
70
Demountthecoverplatetothebelttensioner.
IfthemachineisequippedwithRMC,demounttheRMC(A).
A
g.7219B
71
Loosenthebelttensionerwithatorquewrenchbypullingthetensionplatecounterclockwiseto
thebottom.
g.7218
72
