Wascomat TD67 - Replacement of Damper Motor

62
Heatingunit,steam
10.2Replacementofdampermotor
Disconnectthepowertothemachine.
Demounttheupperrearpanel.
g.7248D
68
Demountthebracket(A)fromthemachineanddemountthedampermotor(B)fromthebracket.
Mountthenewdampermotoronthebracketandthenremountthebracketonthemachine.
Note!
Ifbothofthedampermotorsistobereplaced.Makesuretomountthecorrectmotoron
eachside.Therotationofthemotorsisdifferentandifthemotorsaremountedonthewrong
sidetheywillnotworkproperly.
A
B
g.7249B
69
Remounttheupperrearpanel.
