Drum
11.3.2Replacementofthebeltaroundthemotorpulley
Disconnectthepowertothemachine.
Demountthetworearpanels.
g.7215E
103
Demountthecoverplatetothebelttensioner.
g.7219D
104
Loosenthebelttensionerwithatorquewrenchbypullingthetensionplatecounterclockwiseto
thebottom.
g.7218
105
