Drum
81
Loosenthewire(A)betweenthespringandthepulley.
Note!
Thewirecanbesharpsoitisrecommendedtousegloves.
Loosenthebeltaroundthepulley(B).
A
B
g.7220C
106
Demountthemotormodule.Carefullyliftoutthemotormoduleandputitdownwiththefanmotor
coverdownwards.
g.7216A
107
