Wascomat TD67 - Converting Instructions

Heatingunit,gas
57
9.6Convertinginstructions
NotapplicableforJapan.
Disconnectthepowertothemachine.
Demountthelowerbackpanel.
Removetheairreducingplates.
Removethenozzle(1).
Mountthenewsuppliednozzle.
Mountthenewairreducingplatesaccordingtothetable.
1
g.7182
62
Loosenthemeasuringbranchscrew(2)1/4turn;connectamanometertothemeasuringbranch.
Connectthepowertothemachineandselectaprogramwithheat.
Startthemachine.
Setthecorrectnozzlepressureaccordingtothetableonsettingscrew(4)underthecoverscrew(3).
2
3, 4
g.7120
63
