Wascomat TD67 - Program Unit; Description

90
Programunit
12Programunit
12.1Description
Theprogramunitiselectronicandcomprisesacircuitboardcontainingmicroprocessor,program
memory,serialinterfacetothemotorcontroletc.
Theprogramunitreceivesitspowerfromaseparatevoltageunit.
g.7356
125
TheprogramunitreceivesinformationfromtheI/Oboardsaboutinputliketemperaturesensors,
RMC,vacuum,doorstatusetc,andoutputlikedrum,fanandheatcontrol.
