Sensorsandoverheatingthermostats

5.3.2Heatingsensor(NTC-sensor)

Function

Theheatingsensorisplacednexttothefanmotoronthebackofthemachine.

TheheatingsensormeasuresthetemperatureintheoutletairandthesignalisreturnedtothePCB.

ThePCBturnstheheatingunitoffwhentheoutletairthermistorindicatesthattherequired

temperaturehasbeenreached.

Replacementofheatingsensor(NTC-sensor)

Disconnectthepowertothemachine.

Demountthelowerrearpanel.

Disconnecttheheatingsensorandremoveit.Connectthenewheatingsensorandputitinposition.

Makesurethesensorgetsallthewayin.

g.W00250A

⑦

Remountthelowerrearpanel.
