Wascomat TD67 - Heating Sensor (PT100)

Sensorsandoverheatingthermostats
21
5.1.2Heatingsensor(PT100)
Function
Theheatingsensorisplacedontheheatingmoduleonthebackofthemachine.
TheheatingsensormeasuresthetemperatureintheinletairandthesignalisreturnedtothePCB.
ThePCBturnstheheatingunitoffwhentheinletairthermistorindicatesthattherequired
temperaturehasbeenreached.
Replacementofheatingsensor(PT100)
Disconnectthepowertothemachine.
Demounttheupperrearpanel.
Disconnecttheheatingsensorandremoveit.Connectthenewheatingsensorandputitinposition.
Makesurethesensorgetsallthewaydown.
ElandGasheatedmachine.
Steamheatedmachine.
Remounttheupperrearpanel.
