Wascomat TD67 - Page 82

82
Drum
Inordertoloosenthebelt,rstloosenthefourscrewsabit.
1 2 3 4
g.490377800
108
Loosenthebelt(C)fromthe“motorarm”.
C
D
g.7224A
109
Putthenewbeltinposition(C)andtightenthescrews.Startbytightening1and3abit.Thighten
4andcheckthebelttensionwithafrequencymeaterorsimilar.Thefrequencyshallbe80Hz±
5.Adjustwith4ifnecessary.Thentighten2withtighteningtorque80Nm±5andnally1and
3withtighteningtorque6Nm±1againwhenallisinposition.
1 2 3 4
g.49077800A
110
