38
Motor
Removethescrewandwasher.
g.W00222A
33
Useapullertoremovethefanfromthefanmotor.
Demountthefanmotorbyunscrewingthefourscrews(1–4).
Mountthenewfanmotor.Tightenthescrewscrosswise(1,4,2and3)withtighteningtorque
16.5Nm±3.0Nm.
1
2 3
4
g.W00224A
34
