Heatingunit,gas
Demountthegasvalvefromthegasunit.
g.7275
55
Mountthenewgasvalveonthegasunit.
Remountthegasunitinthemachine.
Connecttheearthcable.
Connecttheamesensorandtheignitioncableonthecontrolbox.
Fastenthescrewtothecontrolbox.
Connecttheheatingsensor(PT100)andtheoverheatprotection.
Fastenthescrewstothebracketholdingthegasvalve.
Remountthetworearpanelsandconnectthegasinlet.
