Wascomat TD67 - Page 78

78
Drum
Whenremountingthedrum,rstfastenthenewbelttemporarelyontheouterdruminthemachine,
thenputthedruminposition.
g.W00229
101
Fastentheboltandthewasherandremountthebearingcover.Usetighteningtorque20Nm±3Nm.
OnmachineswithRMC;pulltheRMCangebackinpositionandtightenthescrew.Usetightening
torque5Nm±0.5Nm.
Pushthebeltfromtheouterdrumontotheinnerdrumandmakesureitisinposition.
Fastenthebelt(B)andthewire(A).Rotatethedrumtomakesurethatthebeltisinposition.
Tightenthebelttensionerwithatorquewrenchbypullingthetensionplate(E)clockwiseuntil
itisinposition.
Checkthebelttensionwithafrequencymeaterorsimilar.Thefrequencyshallbe75Hz±5Hz.
Adjustifnecessary.
A
B
E
B
g.7220D
102
