Waters Prep Series - Attaching the Interface Cable and Power Cord

Assembling the system 2-13
External device connections requiring auxiliary power
Connecting accessories
To connect a PowerLine autoinjector (Waters 717plus), see “IEEE-488 cables
with external PowerLine devices” on page 2-17. To connect autoinjectors other
than PowerLine devices, see “Using an autoinjector” on page 2-41.
To connect fraction collectors, see “Connecting a fraction collector” on
page 2-42. To connect PowerLine detectors (Waters 2487 and 2414), see
“IEEE-488 cables with external PowerLine devices” on page 2-17. To connect
detectors other than PowerLine devices, consult the documentation supplied
with the detector.
Attaching the interface cable and power cord
You need to make the following cable connections for PrepLC controller use:
• Attaching the pump interface cable
• Attaching the AC power cord
CHART +
PRESSURE +
CHART —
PRESSURE —
INJECT
STOP FLOW HOLD S1 S2 S3 S4
SWITCHES
GND GND GND GND
AUX
+12V
External
device
