Table 2–1: Flow rate versus temperature and gas flow:
Flow rate (mL/min) Source temperature
(°C)
Desolvation
temperature (°C)
Desolvation gas
flow (L/h)
0.000 to 0.020 150 200 800
0.021 to 0.100 150 300 800
0.101 to 0.500 150 500 1,000
>0.500 150 600 1,000
2.8 Preparing the fluidics system
This section contains information for preparing the fluidics system. For additional information, see
Connecting liquid waste lines (Page 163) and Plumbing the fluidics system (Page 173).
Prohibited: To avoid equipment damage caused by spilled solvent, do not place
reservoir bottles directly atop an instrument or device or on its front ledge. Instead,
place the bottles in the bottle tray, which serves as secondary containment in the event
of spills.
2.8.1 Installing the reservoir bottles
Use standard reservoir bottles (15-mL) for instrument setup and calibration. Use the Low-volume
Adapter Kit (sold separately) to infuse smaller volumes. The low-volume vials have a volume of
1.5 mL.
Required materials
Chemical-resistant, powder-free gloves
To install the reservoir bottles:
Warning: To avoid personal contamination with biologically hazardous, toxic, and corrosive
materials, wear chemical-resistant, powder-free gloves when performing this procedure.
1. Remove the reservoir bottle caps.
2. Screw the reservoir bottles onto the mass spectrometer, as shown below.
January 10, 2022, 715006200 Ver. 01 (previously released as Rev. A)
Page 43
