ProtoNode FPC-N34 & FPC-N35 User Manual
CHAPTER 9 – CAS BACNET EXPLORER
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 51 of 140
9.2.2 CAS BACnet BACnet/IP Setup
See Section 4.2 to set the IP Address and subnet of the PC that will be running the CAS
Explorer.
Connect a straight through or cross Ethernet cable from the PC to ProtoNode.
In CAS Explorer, do the following:
o Click on “settings”
o Check the BACnet/IP box and uncheck the BACnet MS/TP and BACnet Ethernet
boxes
o In the “Select a Network Device” box, select the network card of the PC by clicking
on it
o Click “Ok”
o On the bottom right-hand corner, make sure that the BACnet/IP box is green
o Click on “discover”
o Check all 4 boxes
o Click “Send”
