ProtoNode FPC-N34 & FPC-N35 User Manual
APPENDIX C: AERCO EQUIPMENT POINT MAPPINGS
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 79 of 140
Appendix C-6: ACS/BMSII/BMS Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus TCP/IP and
LonWorks
Appendix C-6: ACS/BMSII/BMS Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2, Modbus TCP/IP and LonWorks
Name
Point Name
BACnet
Object
Type
BACnet
Object
ID
N2
Data
Type
N2 Point
Address
Lon Name
Lon SNVT
Modbus
Address
Fire Rate Out
boilerstate_XXX
AV
1
ADF
1
nvoBlrState_XXX
SNVT_count_inc
30005
Header Set Temp
effectsetpt_XXX
AV
2
ADF
2
nvoEffSetpt_XXX
SNVT_count_inc
30006
Net Header Set
Temp
setpt_XXX
AV
3
ADF
3
nviSetpt_XXX
SNVT_count_inc
40005
Header Temp
localsuptemp_XXX
AV
4
ADF
4
nvoLocSupTmp_XXX
SNVT_count_inc
30002
Outside Air Temp
localoatemp_XXX
AV
5
ADF
5
nvoLocOATmp_XXX
SNVT_count_inc
30003
Display Code
dispcode_XXX
AV
6
ADF
6
nvoDispCode_XXX
SNVT_count_inc
30011
Number Boilers Fired
blrfired_XXX
AV
7
ADF
7
nvoBlrsFired_XXX
SNVT_count_inc
30008
Number Boilers
Online
blronline_XXX
AV
8
ADF
8
nvoBlrOnline_XXX
SNVT_count_inc
30009
Last Boiler Fired
blrlast_XXX
AV
9
ADF
9
nvoLastFired_XXX
SNVT_count_inc
30017
Boiler 1 Status
blr1stat_XXX
AV
10
ADF
10
nvoBlr1Stat_XXX
SNVT_count_inc
30018
Boiler 2 Status
blr2stat_XXX
AV
11
ADF
11
nvoBlr2Stat_XXX
SNVT_count_inc
30019
Boiler 3 Status
blr3stat_XXX
AV
12
ADF
12
nvoBlr3Stat_XXX
SNVT_count_inc
30020
Boiler 4 Status
blr4stat_XXX
AV
13
ADF
13
nvoBlr4Stat_XXX
SNVT_count_inc
30021
Boiler 5 Status
blr5stat_XXX
AV
14
ADF
14
nvoBlr5Stat_XXX
SNVT_count_inc
30022
Boiler 6 Status
blr6stat_XXX
AV
15
ADF
15
nvoBlr6Stat_XXX
SNVT_count_inc
30023
Boiler 7 Status
blr7stat_XXX
AV
16
ADF
16
nvoBlr7Stat_XXX
SNVT_count_inc
30024
Boiler 8 Status
blr8stat_XXX
AV
17
ADF
17
nvoBlr8Stat_XXX
SNVT_count_inc
30025
Net Boiler 1 Status
netblr1stat_XXX
AV
18
ADF
18
nvoNetBlr1Stat_XXX
SNVT_count_inc
30026
Net Boiler 2 Status
netblr2stat_XXX
AV
19
ADF
19
nvoNetBlr2Stat_XXX
SNVT_count_inc
30027
Net Boiler 3 Status
netblr3stat_XXX
AV
20
ADF
20
nvoNetBlr3Stat_XXX
SNVT_count_inc
30028
Net Boiler 4 Status
netblr4stat_XXX
AV
21
ADF
21
nvoNetBlr4Stat_XXX
SNVT_count_inc
30029
Net Boiler 5 Status
netblr5stat_XXX
AV
22
ADF
22
nvoNetBlr5Stat_XXX
SNVT_count_inc
30030
Net Boiler 6 Status
netblr6stat_XXX
AV
23
ADF
23
nvoNetBlr6Stat_XXX
SNVT_count_inc
30031
