CHAPTER 5. SETUP WEB SERVER SECURITY
Navigate to the IP Address of the ProtoNode on the local PC by opening a web browser and
entering the IP Address of the ProtoNode; the default Ethernet address is 192.168.1.24.
NOTE:
If the IP Address of the ProtoNode was changed, the assigned IP Address can be discovered
using the FS Toolbox utility. See Section 5.4 for instructions.
5.1 Login to the FieldServer
The first time the FieldServer GUI is opened in a browser, the IP Address for the gateway will
appear as untrusted. This will cause the following pop-up windows to appear.
• When the Web Server Security Unconfigured window appears, read the text and choose
whether to move forward with HTTPS or HTTP.
Figure 5-1: Web Server Security Unconfigured Window
• When the warning that “Your connection is not private” appears, click the Advanced
button on the bottom left corner of the screen.
Figure 5-2: Connection Not Private Warning
