ProtoNode FPC-N34 & FPC-N35 User Manual
APPENDIX B: EQUIPMENT MONITOR AND CONTROL POINT DEFINITIONS
OMM-0150_B 5/20/2021 Technical Support (800) 526-0288 Mon-Fri, 8 am - 5 pm EST Page 65 of 140
SmartPlate EV Points as a part of BST:
Point Name
BACnet
Address
Lon Name
Lon SNVT
Modbus
Reg.
Type
Modbus
Data
Address
Units (Range)
SP Outlet
AV: xx00
nvoSPHTR_yy_1
SNVT_count_inc
Input
3xx00
°F (30 to 245)
SP Valve Position
AV: xx01
nvoSPHTR_yy_2
SNVT_count_inc
Input
3xx01
% (0 to 100)
SP Setpoint
AV: xx02
nvoSPHTR_yy_3
SNVT_count_inc
Input
3xx02
°F (30 to 245)
SP Error #
AV: xx03
nvoSPHTR_yy_4
SNVT_count_inc
Input
3xx03
Error # 0-20
SP Delta Pres
AV: xx04
nvoSPHTR_yy_5
SNVT_count_inc
Input
3xx04
PSI (0 to 100)
SP DHW Inlet
AV: xx05
nvoSPHTR_yy_6
SNVT_count_inc
Input
3xx05
°F (-70 to 245)
SP Flow
AV: xx06
nvoSPHTR_yy_7
SNVT_count_inc
Input
3xx06
GPM (0 to 200)
SP Boiler Inlet
AV: xx07
nvoSPHTR_yy_8
SNVT_count_inc
Input
3xx07
°F (30 to 245)
In this chart “xx” begins at 35 and “yy” begins at 50. “xx” = 35 for Smartplate (SP) at address
50; “xx” = 36 for Smartplate at address 51; and so on.
SmartPlate Boiler Address #50, ‘xx’ = 35
#51, ‘xx’ = 36
#52, ‘xx’ = 37
#53, ‘xx’ = 38
#54, ‘xx’ = 39
#55, ‘xx’ = 40
