ProtoNode FPC-N34 & FPC-N35 User Manual
CHAPTER 1 – Introduction
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 8 of 140
AERCO’s multi-protocol communications gateway supports integration of AERCO devices with
customers’ building control and energy management systems. The plug-n-play package
supports integration with BACnet/IP, BACnet MS/TP, LonWorks, and Johnson Controls Metasys
N2 systems and Modbus TCP. AERCO’s Communications Gateway is available for all AERCO
boilers, water heaters, and electronically controlled indirect systems.
• Built-in translation for BACnet/IP, BACnet MS/ TP, LonWorks, Metasys N2 and Modbus
TCP Protocols
• Supports individual units and systems including AERCO’s WHM and BST.
• Select protocol and baud rate in the field using simple DIP switch selection
• Captures alarm and trend history for faster troubleshooting
• Non-volatile memory retains point mappings and programs in the event of power loss.
• Approvals: BACnet Testing Labs (BTL) B-ASC on ProtoNode FPC-N34, CE Mark,
LonMark 3.4 Certified on ProtoNode FPC-N35, TUV approved to UL 916
Serial ProtoNode FPC-N34
P/N 64168
LonWorks ProtoNode FPC-N35
P/N 64169
Figure 1-2: ProtoNode Dimensions
4.52
[114.91]
4.52
[114.91]
3.25 [82.55]
3.62 [91.98]
3.25 [82.55]
3.62 [91.98]
2.91 [73.91]
2.91 [73.91]
1.60
[40.6]
