ProtoNode FPC-N34 & FPC-N35 User Manual
APPENDIX C: AERCO EQUIPMENT POINT MAPPINGS
OMM-0150_B • 5/20/2021 Technical Support • (800) 526-0288 • Mon-Fri, 8 am - 5 pm EST Page 84 of 140
Point Name
FPC-N34
FPC-N35
Modbus
Address
BACnet
Data Type
BACnet
Object Id
N2 Data
Type
N2 Point
Address
Lon Name
Lon SNVT Type
Brnr Ctrl id date Reg 1
AI
91
AI
91
nvoBrnIDDtR1_XXX
SNVT_count_inc_f
40109
Brnr Ctrl id date Reg 2
AI
92
AI
92
nvoBrnIDDtR2_XXX
SNVT_count_inc_f
40110
Brnr Ctrl id date Reg 3
AI
93
AI
93
nvoBrnIDDtR3_XXX
SNVT_count_inc_f
40111
Brnr Ctrl id number
AI
94
AI
94
nvoBrnIDNum_XXX
SNVT_count_inc_f
40112
Software version AZL5
AI
95
AI
95
nvoSw_AZL5_XXX
SNVT_count_inc_f
40113
Software version Brnr Ctrl
AI
96
AI
96
nvoSwBrnCtrl_XXX
SNVT_count_inc_f
40114
Software version load Ctrller
AI
97
AI
97
nvoSwLdCtrl_XXX
SNVT_count_inc_f
40115
Brnr id Reg 1
AI
98
AI
98
nvoBrnr_ID1_XXX
SNVT_count_inc_f
40116
Brnr id Reg 2
AI
99
AI
99
nvoBrnr_ID2_XXX
SNVT_count_inc_f
40117
Brnr id Reg 3
AI
100
AI
100
nvoBrnr_ID3_XXX
SNVT_count_inc_f
40118
Brnr id Reg 4
AI
101
AI
101
nvoBrnr_ID4_XXX
SNVT_count_inc_f
40119
Brnr id Reg 5
AI
102
AI
102
nvoBrnr_ID5_XXX
SNVT_count_inc_f
40120
Brnr id Reg 6
AI
103
AI
103
nvoBrnr_ID6_XXX
SNVT_count_inc_f
40121
Brnr id Reg 7
AI
104
AI
104
nvoBrnr_ID7_XXX
SNVT_count_inc_f
40122
Brnr id Reg 8
AI
105
AI
105
nvoBrnr_ID8_XXX
SNVT_count_inc_f
40123
Min-output gas
AI
106
AI
106
nvoMinOutGas_XXX
SNVT_lev_percent
40124
Max-output gas
AI
107
AI
107
nvoMaxOutGas_XXX
SNVT_lev_percent
40125
Min-output oil
AI
108
AI
108
nvoMinOutOil_XXX
SNVT_lev_percent
40126
Max-output oil
AI
109
AI
109
nvoMaxOutOil_XXX
SNVT_lev_percent
40127
Load limit enduser
(modulating)
AV
110
AO
110
nvi/nvoLdLmEndMd_XXX
SNVT_lev_percent
40128
Load limit enduser (multistage)
AV
111
AO
111
nvi/nvoLdLmEndMs_XXX
SNVT_count_inc_f
40129
temp limiter switching
differential ON
AI
112
AI
112
nvoTmpLmSwDf_XXX
SNVT_lev_percent
40130
Measuring range temp sensor
AI
113
AI
113
nvoMsrRgTpSn_XXX
SNVT_count_inc_f
40131
Adaption active/inactive
AI
114
AI
114
nvoAdpActv_XXX
SNVT_count_inc_f
40132
Adaption state
AI
115
AI
115
nvoAdpState_XXX
SNVT_count_inc_f
40133
Start adaption
AV
116
AO
116
nvi/nvoStrtAdap_XXX
SNVT_count_inc_f
40134
Adaption output
AV
117
AO
117
nvi/nvoAdapOut_XXX
SNVT_lev_percent
40135
P-value
AV
118
AO
118
nvi/nvoP_Value_XXX
SNVT_lev_percent
40136
I-value
AV
119
AO
119
nvi/nvoI_Value_XXX
SNVT_time_sec
40137
D-value
AV
120
AO
120
nvi/nvoD_Value_XXX
SNVT_time_sec
40138
Current Lockout Error code
AI
121
AI
121
nvoCrLkErCod_XXX
SNVT_count_inc_f
40401
