The 8 standard buttons are the following:
These arrows allow you to move through the menu options
and the data stored in memory.
allows to validate an option or enter in a menu.
always allows to come back to the main screen (measuring
screen).
allows to get back to an earlier menu or to cancel a selection.
allows to take print-screens anytime.
The top of the SMP2 holds the eld probe connector.
• Probe connector: ( see 4.2).
ON / OFF button: switches the equipment on and off.
• Status LED: when the unit is off, red means charging, green charged. When
the unit is on, green LED should be always on.
• Light sensor: allows to control the automatic screen back-light intensity
depending on ambient light.
t u
p
q
Figure 3: Top
Probe connector
Light sensor
ON/OFF button
Integrated GPS
patch antenna
Status LED
User’s Manual Electromagnetic Field Meter SMP2 P. 11
