RS485 TO ETH
User can set RS485 TO ETH in HTTPD Client mode and related parameters by web server as follow:
Figure 10 HTTPD Client
2.3. SERIAL PORT
2.3.1. SERIAL PORT BASIC PARAMETERS
Table 1 Serial Port Parameters
2.3.2. VCOM APPLICATION
User can download VCOM software from Waveshare Wiki. Through this software user can set up
connection between RS485 TO ETH and virtual serial to solve the problem that traditional equipment
PC software used in serial port communication way.
2.3.3. SERIAL PACKAGE METHODS
Parameters
Default
Range
Baud rate
115200
600~230.4Kbps
Data bits
8
5~8
Stop bits
1
1~2
Parity
None
None, Odd, Even, Mark, Space
