Page #22 background imageLoading...
Page #22 background image
RS485 TO ETH
3.2. WEB SERVER CONFIGURATION
User can connect PC to RS485 TO ETH through LAN port and enter web server to configure. Web
server default parameters as follow:
Table 2 Web Server Default Parameters
Parameter
Default settings
Web server IP address
192.168.0.7
User name
admin
Password
admin
After firstly connecting PC to RS485 TO ETH, user can open browser and enter default IP 192.168.0.7
into address bar, then log in user name and password, user will enter into web server. Web server
screenshot as follow:
Figure 21 Web Server
