REFERENCE DESIGNATORS PARTDESCRIPTION
ORIG-MFGR-PART-NO MFGR WAVETEK NO . OTY
14
SWP OSC,M9W-2 M9W-2 W-1
1114-00-0038 1
C4,9 C50
CAP,CER,470PF,1 .4KV
E61UWAUW471M1 .4KV MDC 151'0-11-0471 2 .
CD115-147
C1 THRU C48
CAP,CER,F .T . 1000PF 54-794-010-102P SPEC 1510-30-8102
48
CF112-210
L1 L2
FERRITECHOKE T1255-1 HYT 1810-05-0001
2
LA009-004
32 CONN- 5-CKT
07-01-7051 MOL 2113-00-0002 1
33 TERMINAL,M0000-10505-02-0050
MOL 2113-01-0001 4
24 RECEPTACLE
.MC000-016 03-06-1151 MOL 2113-03-0001 1
22 RECEP,36-PIN
03-06-1361 MOL 2113-03-0004 1
M0000-054
25
PLUG,M0000-017 03-06-2151
MOL 2113-04-0001 1
23
PLUG,36-PIN 03--06-2362
MOL 2113-04-0005 1
M0000-055
26 TERMINAL-FEMALE
02-06-1131 MOL
2113-05-0001 45
M0000-018
27 TERMINAL,MALE
1854 MOL 2113-05-0002
45
MCOOO-019
WAVETEK
TITLE
ASSEMBLY NO . REV
OPT 7,REDLEAKAGE
1019-00-0006 C
PARTS
LIST
PAGE : 1
