Wavetek 3000 - PLL #3 Operation; Crystal Reference

To provide phase locking in 1 kHz steps,
the PLL #4 phase detector's reference
from PLL #1 is adjustable in 1 kHz steps
(10 .000 to 9 .001 MHz) . This causes the
Wide Oscillator frequency to change in
1 kHz steps in order to keep the loop
locked .
PLL
#3
The purpose of PLL #3 is to stabilize the
Narrow Oscillator at a frequency of 1198
MHz .
Figure 3-6 showsa simplified block dia-
gram of PLL #3 . This loop operates in
the same manner as PLL #1 and PLL #2
except that it doesnot require the use
of a
programmable
counter
.

The
1198
MHz output from the Narrow Oscillator
is combined in a mixerwith a 1200 MHz
crystal controlled signal .

This pro-
duces a 2 MHz difference signal .

This
signal is fed to a phase detector where
it is
compared to a 2 MHz crystal ref-
erence
.

Anydifference in the input sig-
nals will produce an
error

voltage
which is
applied to the Narrow Oscilla-
tor (VCO) to correct the frequency error .
To provide
FM
modulation, the
2 MHz
crystal reference
applied to
the phase-
detector in
PLL
#3 is replaced with the
output of a VCO as shown in Figure 3-7 .
Ea'T
.
Moo
/,PI/ r
Figure
3-7 . FM Circuit
CRYSTALREFERENCE
?MHz
X r .4[
lNOlIT
THFORY OF OPFRATION
With a
O volt (0
deviation) input to the
VCO of Figure 3-7, the output is 2 MHz,
therefore the operation of the generator
is unchanged except the frequency
accu-
racy is reducedbecause the reference is
not now crystal controlled .
A modula-
ting signal of +5 V to -5
V
will cause
the VCO frequency to shift 0 .5 MHz above
and below the 2 MHz signal . Since the
instrument's RF outputsignal is phase
locked to this reference the output of
the generator will be FM modulatedwith
a
maximum
deviation of .5
MHz .
All
the reference frequencies for the
phase-locked loops
are derived from a
single 40 MHz crystal source by means of
appropriate multiplication or division .
Figure 3-6 . PLL #3
/ZOO .Wz
XTAL
INOUT
TO AEwER rm E /NPUT
PL /
Atx
TO
OUTPUT
MIXER
