15
Peugeot 207
1 Loosely fit the bracket
2 M6x16 bolt [2x], spring washer [2x]
Assem-
bling the
bracket
1 Original vehicle bolt [2x]
Tighten the loosely pre-assembled M6x16
bolt with the spring washers [2x].
Assem-
bling the
strut
Installing the Heater Unit
For gasoline vehicles only
Ejot screw bolts tightening torque 10 Nm!
Insert two washers between the heater unit
and the bracket in position 2.
1 Ejot screw bolt [2x]
2 Ejot screw bolt
Assem-
bling the
heater unit
For diesel vehicles only
Ejot screw bolts tightening torque 10 Nm!
Insert two washers between the heater unit
and the bracket in position 2.
1 Ejot screw bolt [2x]
2 Ejot screw bolt
Assem-
bling the
heater unit
21
1
2 2
22
1
1
23
1
1
2
24
1
1
2
