Peugeot 207
Validity
Vehicle and engine types, equipment variants as well as national specifications, which are not listed in
these installation instructions, have not been tested. Installation according to these installation
instructions may, however, be possible.
The installation location of a time switch and summer / winter switch should be confirmed with the end
customer before installation.
Manufacturer Model Type EG-BE No. / ABE
Peugeot W 207 e2 * 2001 / 116 * 0340
Engine type Engine Power in kW Engine capacity in cm³
KFU Gasoline 65 1360
NFU Gasoline 80 1587
9 Hz Diesel 80 1560
Validity 2
Heater Unit / Installation Kit 3
Foreword 3
General Instructions 3
Special Tools 3
Explanatory Notes on the Document 4
Preliminary Work 5
Heater Unit Installation Location 5
Preparing the Electronics 6
Electrical Connections 8
Manual air conditioning blower control 9
Automatic air conditioning blower control 10
Remote Start Option 13
Preparing the Heater Unit 14
Preparing the Installation Location 14
Installing the Heater Unit 15
Water Connection for Gasoline Engines 16
Water Connection for Diesel Engines 19
Combustion Air 22
Fuel Connection 23
Exhaust System 26
Final Work 28
Operating instructions for the end customer 29
Petrol vehicle tank extracting device template 30
Diesel vehicle tank extracting device template 31
