Webasto Thermo Top C User Manual

6
Peugeot 207
Preparing the Electronics
Only for automatic air conditioning
Wire sections 3, 4, 5, 7 for K3.1 relay
connection
Wire sections 1, 2, 6, 8 for connecting the
IPCU.
Cutting
wires into
sections
Cutting
wires into
sections
Connect according to the circuit diagram.
Pull the wire section 9 into the enclosed
insulating hose.
Pre-
assem-
bling the
K3 relay
Connect according to the circuit diagram.
Pre-
assem-
bling the
K3.1 relay
300
2
rt 0,5mm²
700
1
rt 0,5mm²
300
3 4
300
300
6
sw 0,5mm²
700
5
br 0,5mm²
300
7 8
300
86
85 30
87a87
K3
br sw
rt/ws
9
gn/ws
gn/ws
86
85 30
87a87
K3.1
3
rt
5
swbr
7
4
rt
