22
Peugeot 207
Combustion Air
1 Original vehicle bolt
2 Angle bracket
3 Combustion air intake silencer
4 Cable clip
Cutting the
combus-
tion air
pipe into
sections
1 Combustion air intake pipe
2 Ø 27 mm hose clamp
Assem-
bling the
vacuum
line.
1
4
2
3
37
38
1
2
i
