Webasto Thermo Top C User Manual

9
Peugeot 207
Manual air conditioning blower
control
Connection to the 6-pin plug connection IC 26
3
from the blower motor cable harness.
Connect with enclosed butt connectors
according to the circuit diagram.
1 Black (sw) wire from K3/30
2 White (ws) wire to connector IC 26
4 White (ws) wire from main power supply
PSF 1
5 Red (rt) wire to K3/87a
Connec-
ting the
blower
motor
Manual air
condition-
ing circuit
diagram
Webasto components Components Peugeot 207 Colors and symbols
Legend
HG Heater unit TT-C/E 8050 Blower motor rt red
X1 6-pin connector 8025 Air conditioning control ws white
F3 Fuse, 25A PSF1 Main power supply sw black
K3 Blower relay IC 26 6-pin connector br brown
gn green
X Splitting point
Cable colors may vary.
6
1
4
2
5
3
gn/
ws
ws
sw
rt/ws
rt
Webasto
31
30
15
Peugeot
ws
rt
HG
4
X1
F3
86
85 30
87a87
K3
PSF 1
F11
R7
2
2V NR
8025
8V NR
1
8050
2V NR
2
M
1
3
IC26
6
i
